Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combined Water Treatment
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Items Specification
Model TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC)
Main Product List Double Combustion Chamber
Smoke Filter Chamber
PLC Mode Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Nanjing Clover Medical Technology Co., Ltd..

Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER
Origin:Nanjing
Production Capacity:1000 Sets Per Year

Product Description

2011 year is an important base for us. We reach developed country market and stabilize our older customers. Our incinerator use in Southeast Asia, Central Asia, Europe, small scale garbage incinerator, small scale gas incinerator, small scale incenaration, scale incineration, small scale incinerator cost, small scale incinerator designs, Middle East, Africa and Australia, etc.. Clover Incinerator has become one of the famous and biggest incinerator supplier all over the world.

Merchandise Main Application:  1. Medical waste incineration treatment.  2. Pet/Animal cremation business.  3. Municipal waste and other solid waste treatment.

We can supply different model & design incinerator products for different market request. Our large capacity incinerator(300/500kgs per hour) accept by customers and market finally.

Animal Carcass Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER

Product Description

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *based on order  * High fever, long lifetime of incinerator.  * Free or minimal installation on site.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and components in stock.

Presently, we provide different series for local customer requirements and design upgraded incinerator with our leading technology. Animal iacinerator, creature incincerator pricing, animal incineration, animal incineration emerging technologu, animal incineration equipment in china, animal incineration equipment  Costs, The updated design feature of our assortment of incinerators make them one of the most cost effective in the world.

Items Specification
YD Model YD-30 / YD-50 / YD-100 / YD-150 / YD-200 / YD-300 / YD-500 / YD-600
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Mix Combustion Chamber
Smoke Filter Chamber
Incinerator Common Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

New Courtice incinerator hits further delays

CLARINGTON — Clarington’s new energy-from-waste facility will be delayed a second time since the boilers are not operating properly and the continuing startup period could cost Durham Region an extra $1 million.

“I’d rather see it delayed and done right than rushed,” said Clarington Mayor Adrian Foster.

The Durham York Energy Centre facility, located in Courtice, was scheduled to be fully operational on Dec. 14, 2014. Now the Durham York Energy Centre is not expected to be in full working order before the last quarter of 2015.

The significant systems of the EFW facility have been analyzed. The boiler temperature is high enough for the combustion process but the steam temperature isn’t high enough, and officials are not sure what the issue is, says Durham’s works commissioner, Cliff Curtis.

The steam temperature needs to be high enough to drive the turbine-generator. If the steam is too cool it may damage the turbine.

“It’s like running a car without oil,” said Mr. Curtis.

Covanta, the business building and operating the facility for Durham and York regions, has taken down the boilers for alterations, according to Mr. Curtis. It’s expected to take three weeks for the repairs and alterations. Then there’ll be a four-week demonstration period, followed by a 30-day acceptance test.

“We are not getting the temperature we expected out of the boiler. “It’s Covanta’s problem to provide us the product that performs the way they said, so they’re going to take the time they require.”

The delay means added consultant costs for construction management, legal advice and baseline ambient air monitoring. A Durham Region works report stated Durham’s share of the extra costs is $1 million, which can be provided by a temporary draw on the solid waste management reserve fund.

“What’s the last cost going to look like?” Stated Clarington Regional Councillor Joe Neal, who added that he still has concerns about the emissions meeting the Ministry of Environment rules.

Since Jan. 16, Durham has been charging Covanta a $10,000-a-day late fee for each day the EFW facility is not fully operational. The invoice was sent to Covanta, but it hasn’t been paid yet, according to Mr. Curtis.

In mid-February, the incinerator started burning its first haul of curbside garbage. It was a part of a testing phase before the centre opens completely.

Durham cancelled landfill contracts and started sending crap to the Courtice facility. Some garbage was burned at the EFW plant during the evaluation phase, without generating power to the grid. Covanta has also been sending the trash to its incinerator in New York state, or landfills in the Niagara region.

Until the EFW facility is up and running, the Region only pays Covanta half cost of the agreed upon per-tonne fee. However, Durham isn’t earning any money until the plant is fully operational and selling electricity back on the grid.

“We are still on budget. I’d rather be getting electricity sales on the grid,” said Mr. Curtis.

The plant construction is coming in slightly under budget, according to the works commissioner.

There are a few loose ends that could wind up costing Durham Region more cash. There’s still debate with former property owners on the value of the land expropriated for the center, and a ruling is not expected until fall of next year. The final cost for the utility construction and connection costs is expected in coming months. The baseline ambient air monitoring runs until the EFW facility is operational, so the delay in opening signifies an ongoing monitoring cost.

“There’s some small cost over-runs on a few of the smaller items but generally we’re financially on track to bring this on budget and we look forward to having it on line by the end of the year,” said Mr. Curtis.

HOW THIS IMPACTS YOU

The Durham York Energy Centre is designed to process up to 140,000 tonnes of waste each year, and generate 17.5 gross megawatts of renewable energy — enough to electricity between 10,000 and 12,000 houses. A vital part of the financial case for the energy-from-waste facility is dependent upon it generating electric power revenue.

from: http://www.durhamregion.com/news-story/5682601-new-courtice-incinerator-hits-further-delays/

Melt blown Production Line 400mm and 1600mm and ES Fiber Production Line and N95 Mask Machine and Disposable Mask Machine

1. 400mm and 1600mm Melt blown Production Line

3. ES Fiber Production Line







N95 Face Mask Machine Production Line

Melt blown Production Line



A.)Optional Capacity: 1600mm

Efficiency: 95-97percent

FOB Term Cost: USD per set

Price Valid: 5days.

Ave.60 Days ready for shipping.

In stock Price: USD per set





B.)Optional Capacity: 400mm

Efficiency: 40-50%.

FOB Term Cost: USD per set

Price Valid: 5days.

Ave.20 Days ready for shipping.

Payment: TT 70% In advance, TT 30% before leave factory

Shipping: 1*20′ container per set, Ave. 2000Kgs.



Main Parts: Extruder, mold, winder, oven, ultrasonic

Daily Capacity:100-150Kgs/24Hours

Screw extruder:100-150Kgs

Motor power: 15KW frequency conversion speed regulation Reducer speed ratio: 1:10 or 1:16 Screw length to diameter ratio: 30: 1 Screw diameter: 50mm Winding machine diameter: £ 630mm Winding machine drive motor power: 0.55kw speed ratio of winder drive reducer (if any): 1:71 Air heater power: 15kw Power of vacuum calciner: 12kw The magnitude of vacuum calciner: 500 × 300 × 200 Ultrasonic power: 1800, frequency 28kHZ Ultrasonic sink size: 800 × 300 × 250







HICLOVER – Medical Environmental

2020-04-20




Tel: +86-25-8461 0201
Email3: [email protected]
Wechat: 008613813931455
Email1: [email protected]
Twitter ID: @hiclovercom
Website1: www.incinerator-scrubber.com
Email2: [email protected]
WhatsApp: 008613813931455
Website2: www.clover-incinerator.com

Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



2020-04-20

Incinerator A4000

Basic Info.

Model NO.:A4000
Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items/Model A1500 A2400 A4000 A5500
Burning Rate *animal 90 kgs/Hr. 150 kgs/Hr. 200 kgs/Hr. 400 kgs/Hr.
Feed Capacity *animal 120 kgs 200 kgs 300 kgs 500 kgs
Equipment Weight 7000 kgs 8300 kgs 13000 kgs 16500 kgs
Primary Chamber (Liters) 1500 2400 4000 5500
Secondary Chamber (Liters) 500 1200 1500 1500
External Dimensions (cm) 240x170x380 260x220x420 320x220x460 360 x 220 x 475
Internal Dimensions (cm) 150x100x96 220x110x100 257x147x108 300 x 147 x 125
Oil Tank(Liters) 500 500 500 500
Door Opening (cm) 59 x 81 90 x 110 108 x 128 108 x 128
Chimney (M) 10 10 14 14
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES
1st. Chmaber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
2nd. Chmaber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High fever, long life of incinerator.  * Free or minimum installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and components in stock.

Waste Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:CLOVER
Origin:China
Production Capacity:1000 Sets Per Year

Product Description

First, we are one manufacturer in China. We are in this field from year 2005 and at that time, we create trading company to oversea. Under support of our customer, like our agent in Egypt, Mr. Ibrahim, solid waste incinerator boiler manufacturers, solid waste incinerator diesel, solid waste incinerator korea, solid waste incinerator manufacturer new hampshire, we start to enlarge our incinerator business. We have our own workshop in Nanjing city liuhe economic zone and we have 20-30 workers. Up to now, oversea market is own main market and from year 2011, we’ll dig China market.

Abandoned Object Incinerator

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Incinerator is a incineration equipment, direct fire waste by gas fuel or oi fuel. As different circumscription, incinerator can be termed many words as below:

Therapy capacity: Small scale incinerator, large scale incinerator and incineration pant.  Waste material: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, human cremators  Incinerator gas: Gas incinerator, oil incinerator  Waste to Energy (WTE): WTE incinerator, non-WTE incinerator  Incinerator Manufacturer: China incinerator manufacturer, UK incinerator manufacturer, USA incinerator manufacturer, India incinerator manufacturer.  Famous Incinerator manufacturer company: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)  Burning Rate: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Pyrolytic incineration technical is traditional waste treatment way for many years. All around the world, in most countries, people anti incinerator since the incinerator will produce a large Dioxin in the smoke. “Dioxins” refers to a group of poisonous chemical compounds that share certain chemical structures and biological characteristics. Dioxins can be released to the small scale incinerator for home, small scale incinerator for homes, small scale incinerator for solid waste, small scale incinerator for solid waste at price of $250000, environment through forest fires, backyard burning of trash, certain industrial activities, and residue from past commercial burning of waste. Dioxins break down very slowly and past releases of dioxins from both natural and man-made resources still exist in the environment. Anyhow, we must remind that, this is large scale incineration pant, generally more than 30 ton each day. This is a social problem, to analyze and suggest ways in various angles from the general public, government, economic development, environmental protection, technology development, etc..

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

Pathalogical Incinerator

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Company License No.,: 320105000138343  Taxation Certificate No.: 320105571573734  Export Business Certificate No.: 3201571573734

Nanjing Clover Medical Technology Co., Ltd..

Incinerator is a incineration equipment, direct fire waste by gas fuel or oi fuel. As different circumscription, incinerator can be termed many words as below:

Treatment capacity: Small scale incinerator, large scale incinerator and incineration pant.

Waste material: Municipal waste incinerator, pet cremation incinerator costs, pet cremation incinerators price, pet cremation incinerators costs, pet cremation labels, pet cremation machine, medical waste incinerator, animal cremation incinerator, human cremators

Incinerator gas: Gas incinerator, petroleum incinerator

Waste to Energy (WTE): WTE incinerator, non-WTE incinerator

Incinerator Manufacturer: China incinerator producer, UK incinerator manufacturer, USA incinerator manufacturer, India incinerator manufacturer.

Famous Incinerator manufacturer company: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)

Item Customer Request Example
Application Scope



Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%


Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^…unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?

1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination

Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information




Burning Rate: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Waste Incineration Equipment

Basic Info.

Export Markets:Global

Additional Info.

Trademark:CLOVER
Origin:Pr China
Production Capacity:1000 Sets Per Year

Product Description

2.

In year 2011, one Macau (China) place an order of incinerator, version SYC-30. This order under CIF business term and the carton ship via Hongkong port. Our shipping agent inform us there is a mishap at Hongkong when upload & download, but we donot understand details. After we understand this news and inform our Macau customer immediately and ask him check carefully when accept carton. Unfortunately, customer accept carton before check it. As soon as they open the carton, there is some damage of the small incinerators for sale, small incinerators united states, small insenerator for sale, small lab incinerator, small light oil burner, small marine incinerator, equipment. Under this sort of situation, insurance company cannot indemnify because client accept carton and sign document.  Customers should be aware of that buyer bear all risks of loss of or damage to the goods from the time they have passed the ship's rail at the named port of shipment. We proposal apply All Risks insurance under each contract. When purchaser pickup goods at local website, must inspect carefully. If any damage happened under insurance policy, buyer should inform insurance company and Clover Medical Limited promptly. We’ll provide necessary aid.

Incinerateur

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover
Origin:China
Production Capacity:1000 Sets Per Year

Product Description

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to sequence * High temperature, long lifetime of incinerator.  * Free or minimum installation on site.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Nanjing Clover Medical Technology Co., Ltd. is a leading incinerator manufacturer in China. We’re local manufacturer and one of the largest exporter of China. Burner chamber manufacturer, burner combustion, burner gas, burner gas combustion efficiency, burner for medical, burner incinerator LPG, burner untuk incinerator, burners for clinical waste, Now, you can find our incinerator product in the former Soviet Union area, Africa countries, Asia countries and Middle East area. Follow market conditions, we supply different model series and design details according to each order. Clover Medical believe that the best cooperation is trust. The relationship between customer and clover medical isn’t only buyer and seller, we expect to make success together.

Item Customer Request Example
Application Scope



Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%


Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^…unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?

1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination

Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information




Vertical Solid Rubbish Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items Specification
Model TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC)
Main Product List Double Combustion Chamber
Smoke Filter Chamber
PLC Mode Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

The TS PLC model incinerator come instead of SYC model now. SYC model incinerator included model SYC-10/20/30/50/100 and now these model stop supply for market. We provide updated TS PLC versions, more work, PLC controller, stainless steel chimney and reasonable price. TS PLC model incinerator, included TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC).

Small Hospital Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing Clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

The TS PLC model incinerator come rather than SYC model now. SYC model incinerator included model SYC-10/20/30/50/100 and these model stop supply for market. We provide updated TS PLC versions, more function, PLC control, stainless steel chimney and fair cost. TS PLC model incinerator, included TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC).

Bacteria Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

We, Nanjing Clover Medical Technology Co., Ltd., based at China mainland.

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Key Features:  All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High fever, long life of incinerator.  * Free or minimum installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *according to order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Hotel Waste Incinerator

Basic Info.

Export Markets:Global

Additional Info.

Trademark:CLOVER

Product Description

Key Features:  * All models with Dual combustion chamber. *based on order  * Stainless Steel chimney/stack, long life. *according to sequence * High fever, long life of incinerator.  * Free or minimal installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

The mill workshop neighborhood in liuhe Economic Development Zone, suburb of Nanjing and business office neighborhood in downtown area. Presently, incinerator line products marketplace cover former Soviet Union region, Africa countries, Asia countries and middle east area. From year 2010, we negotiated with updated technology from Europe and America producers and establish cooperation relationship in the territory of China market. Animal incinerator bidding 2013, animal incinerator deisgin, animal incinerator for sale price, animal incinerator from china, animal incinerator lpg, animal incinerator per hour, Unfortunately, competition in other countries marketplace, country discrimination and worries of intellectual property rights cause failure ultimately. Presently, we investment more effort, funds and technology development in our own brand, we are to be one of the largest incineration equipment in the world. We have trading division company for professional export business service.

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Smokeless Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing

Product Description

Incinerator is a incineration equipment, direct fire waste by gasoline fuel or oi fuel. As different circumscription, incinerator can be termed many words as below:

Treatment capacity: Small scale incinerator, large scale incinerator and incineration pant.

Waste material: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, human cremators

Incinerator gas: Gas incinerator, oil incinerator

Waste to Energy (WTE): WTE incinerator, non-WTE incinerator

Incinerator Manufacturer: China incinerator manufacturer, UK incinerator manufacturer, USA incinerator manufacturer, India incinerator manufacturer.

Famous Incinerator manufacturer company: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)

Burning Rate: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, model: Syc-30 medical incinerator, model: Syc-10, models for incinerator for biological waste, modern double-chamber pyrolytic incinerators, modern incinerators in china, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Please fill in following items and send back to us. We’ll study following important information and proposal our product models, specification and so forth.

Item Customer Request Example
Application Scope



Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%


Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^..unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?

1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination

Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information




Front Load Waste Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to order  * High temperature, long lifetime of incinerator.  * Free or minimum installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *according to order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Items Specification
Model TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC)
Main Product List Double Combustion Chamber
Smoke Filter Chamber
PLC Mode Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Mine Spews Hazardous Fumes: NWT Air Regulations Not in Place

Snap Lake Mine, 220 kilometres northeast of Yellowknife, where elevated levels of dioxins and furans were pumped into the atmosphere. | Photo Fire Prevention Services

Last July, two incinerators at De Beers’ Snap Lake Mine were belching out clouds of black smoke, one sending an average of 65 times the approved national limit of cancer-causing toxins into the atmosphere.

The hugely elevated levels of dioxins and furans — released when plastic is burned or garbage isn’t fully incinerated — were recorded through a four-day”stack test.” According to the World Health Organization,”dioxins are highly poisonous and can cause reproductive and developmental problems, damage the immune system, interfere with hormones and cause cancer.” The company contracted to perform the testing at Snap Lake discovered that one of the mine’s incinerators was emitting 6.5 times the acceptable limit, while the other incinerator was emitting a whopping 65 times the acceptable limit (5,220 picograms per cubic metre on average, as

emission



It’s uncertain how long this was going on for, although the report noted the problem was clearly visible:”Black opaque smoke was noted for all tests early in the incineration cycle.”

De Beers did not respond to EDGE’s request for a meeting by the time of publication. But, according to a letter from De Beers’ Environment and Permitting Superintendent, Alexandra Hood, sent to the GNWT and Environment Canada in January, the root cause of the problem was”not after standardized work practices,” and running the incinerators, which were only installed in 2013, at too low a temperature.

Since flunking the test, De Beers has retrained personnel, rewritten operating procedures and introduced in new policy to shut down the incinerators if they are not meeting the correct temperatures (if it’s safe to do this ), based on Hood’s letter. A review of the Snap Lake incinerators by a GNWT Lands Officer in March indicates De Beers has ameliorated the problem, at least in part:”No concerns were noted during this review,” it says, and”the west incinerator that was burning waste at the time of inspection was emitting apparent exhaust gas with no black smoke coming from the pile.”

whether sufficient steps are taken, however, will not be known for years: another stack test isn’t scheduled until 2019, according to a source close to the issue wishing to stay anonymous.

No GNWT law

The fact that, for an undetermined time period around July 2014, the Snap Lake incinerators were pumping out unacceptable levels of toxic emissions is troublesome in itself. But it points to a much larger problem in the territory; the GNWT does not regulate emissions, require companies to meet the CWS, or mandate stack testing. (The Mackenzie Valley Land and Water Board, likewise, does not regulate air emissions.)

At several points in her letter, Hood notes the lack of regulation, claiming De Beers”will conform with any regulatory requirements regarding incinerator stack testing once enabling legislation is developed and approved in the NWT.”

Without legislation in place, there is nothing to force De Beers or other groups using incinerators (i.e. each mine in the territory), to keep their emissions at a safe level or undertake pile testing on a regular basis. Each mine has an Air Quality and Emissions Management Plan as part of its environmental arrangement, but these plans only dictate coverage requirements, not actual emission targets. And while Hood claims”deficiencies, as measured against the Canada Wide Standards, will be handled through adaptive management and continuous improvement by De Beers,” there is little government oversight of this”continuous improvement” and no fines or other mechanisms to force polluting businesses to remedy their ways.

This problem has been going on for several years. According to a Canadian Press report by 2011, the scientific journal Integrated Environmental Assessment and Management discovered sediments in a lake close to the Ekati Mine that had levels of dioxins and furans 10 times greater than those collected from an uncontaminated lake. The same report cited a 2007 study commissioned by Environment Canada which suggested”extensive, uncontrolled burning of wastes could result in substantial accumulations of dioxins and furans in the local ecosystem, some of which will persist for some 81/2 years at levels approaching those considered to be of toxicological concern.”

“In many cases we are below the level which health agencies would (watch) for…” the study continues,”but we are getting there.

The record says:”Parties are required to take steps to reduce total releases from anthropogenic sources of dioxins, furans… with the goal of their continuing minimization and where feasible (technically and socio-economically), ultimate elimination.” However, it adds,”each jurisdiction will determine the exact means of ensuring compliance” — basically defanging the document by letting states and territories renege on their commitment without any repercussions.

Other jurisdictions have taken proactive steps, bringing in legislation to regulate emissions consistent with the CWS. The GNWT hasn’t. They did bring in guidelines for managing biomedical waste in 2005, but they have been unwilling to control incinerators at mine sites. Their reason? The”waste incinerators operating at remote industrial sites within the NWT… are located on federal crown land and aren’t regulated by the Government of the Northwest Territories,” states a report by 2009.

This might have been true in 2009, but post-devolution it’s no longer true. Since April of last year, the mines are on land managed by the GNWT, yet there have been no moves from legislators to start regulating toxic emissions from mine or other industrial incinerators. The last time the issue was discussed at the legislative assembly in 2011, Weledeh MLA Bob Bromley reported a”loophole in environmental principles is allowing an increasing number of unregulated waste incinerators to discharge extremely toxic chemicals into the land and water.” He suggested,”when we take on new abilities, we must be prepared to move with law.”

Devolution has come, and incinerators are still operating in an unregulated environment. With all the discussion of fracking and opening up new mining projects in the territory, it’s now time, more than ever, for the GNWT to get its act together.



from: https://edgeyk.com/article/mine-spews-toxic-fumes-nwt-air-regulations-not-in-place/





from: https://edgeyk.com/article/mine-spews-toxic-fumes-nwt-air-regulations-not-in-place/



Horizontal Solid Rubbish Incinerator

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Key Features:  * All models with Dual combustion chamber. *according to order  * Stainless Steel chimney/stack, long life. *according to sequence * High temperature, long life of incinerator.  * Free or minimal installation on site.  * PLC Control Plane for Intelligent operation. *according to order  * New Design for pet animal cremation business.  * One year warranty on incinerator and components in stock.

The factory workshop local in liuhe Economic Development Zone, suburb of Nanjing and business office local in downtown area. Presently, incinerator line goods market cover former Soviet Union region, Africa countries, Asia countries and middle east area. From year 2010, we negotiated with updated technology from Europe and America producers and establish cooperation relationship in the territory of China market. Unfortunately, poultry cremation equipment, poultry incinerator china, poultry incinerator in italy, poultry incinerators, poultry incinerators makers, competition in other countries market, nation discrimination and worries of intellectual property rights cause failure finally. Presently, we investment more effort, funds and technology development in our own brand, we are to be one of the largest incineration equipment on the planet. We have trading division company for professional export business service.

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Incinerator Burner

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing

Product Description

Please fill in following items and send back to us. Benefit of petrol hospital incinerator, algeria incinerators, animail incenrator, animal by-products of the incineration plant strategy, animal carcas incineration, We will study following important information and proposal our product versions, specification and so on.

Item Customer Request Example
Application Scope



Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%


Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^..unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?

1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination

Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information




Incinerator

Basic Info.

Model NO.:PLC Incinerator
Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to order  * High temperature, long lifetime of incinerator.  * Free or minimal installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *based on order  * New Design for pet animal cremation company.  * One year warranty on incinerator and parts in stock.

Items Specification
Model TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC)
Main Product List Double Combustion Chamber
Smoke Filter Chamber
PLC Mode Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Incinerator A2400

Basic Info.

Model NO.:A2400
Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER

Product Description

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to sequence * High fever, long lifetime of incinerator.  * Free or minimal installation on site.  *based on order  * New Design for pet animal cremation company.  * One year warranty on incinerator and components in stock.  Is a major waste incinerator manufacturer in China. We’re local manufacturer and one of the largest exporter of China. Pyrolytic incinerator equipment technical is primary waste treatment all the world, for Medical Waste, Animal Incineration, Pet cremation and other Solid wste. The capacity from 10kgs/Hr. To 500kgs/Hr. , up to 6ton per day. Currently, medical waste incinerators manufactures and suppliers, medical waste incinerators vs animal crematory, medical waste incinrators in china, medical waste italy, we supply different series for local customer requirements and design updated incinerator with our leading technology. The updated design characteristic of our range of incinerators make them one of the most cost effective in the world.

Items/Model A1500 A2400 A4000 A5500
Burning Rate *animal 90 kgs/Hr. 150 kgs/Hr. 200 kgs/Hr. 400 kgs/Hr.
Feed Capacity *animal 120 kgs 200 kgs 300 kgs 500 kgs
Equipment Weight 7000 kgs 8300 kgs 13000 kgs 16500 kgs
Primary Chamber (Liters) 1500 2400 4000 5500
Secondary Chamber (Liters) 500 1200 1500 1500
External Dimensions (cm) 240x170x380 260x220x420 320x220x460 360 x 220 x 475
Internal Dimensions (cm) 150x100x96 220x110x100 257x147x108 300 x 147 x 125
Oil Tank(Liters) 500 500 500 500
Door Opening (cm) 59 x 81 90 x 110 108 x 128 108 x 128
Chimney (M) 10 10 14 14
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES
1st. Chmaber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
2nd. Chmaber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree

Incinerator Machine

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:Clover Medical

Product Description

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to sequence * High fever, long lifetime of incinerator.  * Free or minimum installation on site.  *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Incinerator is a incineration equipment, direct fire waste by gas fuel or oi fuel. As distinct circumscription, incinerator can be termed many words as under:

Treatment capacity: Small scale incinerator, large scale incinerator and incineration pant.

Waste material: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, human cremators

Incinerator fuel: Gas incinerator, oil incinerator

Waste to Energy (WTE): WTE incinerator, non-WTE incinerator

Incinerator Manufacturer: China incinerator producer, UK incinerator manufacturer, USA incinerator manufacturer, India incinerator manufacturer.

Famous Incinerator maker company: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)

Burning Speed: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800–1000 degree 800–1000 degree 800–1000 degree 800–1000 degree 800–1000 degree
2nd. Chamber Temperature 1000-1200 degree 1000-1200 degree 1000-1200 degree 1000-1200 degree 1000-1200 degree
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

Incineraot Msw2000

Basic Info.

Model NO.:MSW2000
Export Markets:Global

Additional Info.

Trademark:CLOVER

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items Specification
 Model MSW2000 / MSW3000 / MSW4000 / MSW5500
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Mix Combustion Chamber
Smoke Filter Chamber
Incinerator Common Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

MSW Model is latest design for municipal solid waste and other solid waste. This equipment quality structural for kinds of site, like hospital, environmental department, animal cremation agencies, etc.. CLOVER Incinerator supply updated models with dual combustion chamber, chinese cremator manufacturers, chinese incinerator, chinese incinerator picture, clinical waste incenarator machines in china, cloer incinerator, mix combustion chamber and smoke filter room with refractory lines, and the combustion chamber temperature up to 1200 deg C.

Incinerator

Basic Info.

for Animal:Incinerator
Dosage Form:Incinerator
Type:Incinerator
Function:Incinerator
Export Markets:Global

Additional Info.

Trademark:CLOVER MEDICAL

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

We are one of the greatest waste incinerator manufacturer and exporter of China. Pyrolytic incinerator technical is main waste treatment method all around the world, for Medical Waste, Animal Incineration, Pet cremation and other good waste. Presently, we supply small clover incineration, clover incinerator 500, clover incinerator co., ltd., clover incinerator ltd, clover incinerator manufacturers in china, clover incineratorsand large scale incinerators as local client requirements and design upgraded incinerator with our leading technology.  Nanjing Clover Medical Technology Co., Ltd.. Tel: +86-25-8461 0201 Fax: +86-25-8461 0406 Add: RM. 7411, No. 58 Yunjin Rd., Nanjing, China 210019

Medical Incinerators

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing Clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High fever, long life of incinerator.  * Free or minimum installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and components in stock.

Item Customer Request Example
Application Scope



Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%


Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^..unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?

1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination

Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information




Please fill in following items and send us back. We’ll study following important information and suggestion our product versions, specification and so forth.

10 Kg Waste Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High temperature, long life of incinerator.  * Free or minimal installation on site.  * PLC Control Plane. *according to order  * New Design for pet animal cremation company.  * One year warranty on incinerator and parts in stock.

Incinerator Label

Basic Info.

Export Markets:Global

Additional Info.

Trademark:nanjing clover
Origin:Nanjing Pr China

Product Description

Nanjing Clover Medical Technology Co., Ltd., Neighborhood in Nanjing city, China.

CLOVER supply medical equipment, medical waste incinerators, pet animal cremator, other solid waste treatment equipment, clean room equipment, fan filter units, air filter, etc.. We supply technology support, installation service and customer made.

We are among the greatest waste incinerator manufacturer and exporter of China. Pyrolytic incinerator technical is main waste treatment system all around the world, for oxidizer manufacturers, paper incinerator, pathological incinerator, pdf catalogue incinerator capacity 100kg, Medical Waste, Animal Incineration, Pet cremation and other Solid waste. Presently, we supply small and large scale incinerators as local customer requirements and design updated incinerator with our leading technology.  7411, No. 58 Yunjin Rd., Nanjing, China 210019

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
2nd. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to sequence * High temperature, long life of incinerator.  * Free or minimal installation on site.  * PLC Control Plane. *according to order  * New Design for pet animal cremation company.  * One year warranty on incinerator and parts in stock.

SWRHA chairman: Delay in Charge causes medical waste back-up

Chairman of the South West Regional Health Authority (SWRHA) Dr Lackram Bodoe said a Copy of medical waste at the San Fernando General Hospital had to do with a delay in payment to a contractor and not the malfunctioning of the incinerator.

Responding to complaints about the risks posed by the accumulated medical waste, which comprised amputated limbs, needles, and bloodstained items, Bodoe assured that the $9 million incinerator installed last year was functioning well.

He said it had been allowed to collect because daily paid employees refused to work on Tuesday.

Speaking with members of the media at SWRHA’s symposium on leadership at the Southern Academy of Performing Arts on Wednesday, Bodoe stated:

“I want to give the assurance that the incinerator itself is working nicely.

“This is a new incinerator that was installed last year and the issue had to do with a contractor who was supposed to eliminate the garbage and there was a delay of funding and that is what created a temporary situation yesterday.”

Asked how soon the situation will be rectified, he said:”I have just been given the assurance by the CEO that the matter has been dealt with as we speak, so I expect at the end of the day it’ll be sorted out.”

In addition, Bodoe stated the SWRHA was also considering introducing a new kind of technology, called the radio wave technology for incineration, which was much more atmosphere friendly.

But a Public Service Association representative, who wished to remain anonymous, said the incinerator was breaking down on a regular basis because it was installed last year and wasn’t working at this moment.

“They had to revert to the old incinerator and that is unsafe and unhealthy to people operating that incinerator.

He said employees took the action on Tuesday because since last week they had been assured that the garbage problem would have been sorted out.

Diesel Oil Fired Medical Waste Incenerator 50kg/Hr

Basic Info.

Model NO.:dioxine emission control medical hospital inciner
Export Markets:Global

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items Specification
YD Model YD-30 / YD-50 / YD-100 / YD-150 / YD-200 / YD-300 / YD-500 / YD-600
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Mix Combustion Chamber
Smoke Filter Chamber
Incinerator Common Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High temperature, long lifetime of incinerator.  * Free or minimum installation on site.  * PLC Control Plane. *according to order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Large Capacity Animal Pet Cremation HICLOVER Model A1500 with E-Power Auto.Door

Large Capacity Animal Pet Cremation HICLOVER Model A1500 with E-Power Auto. Door

Model

A1500

Internal Dimensions

150 x 100 x 96cm

Suit for Animal

Cat – yes

Dog – yes

Pig – small

Cow – small

Main Product List

Primary Combustion Chamber

Secondary Combustion Chamber

Mix-Combustion Chamber

Smoke Filter Chamber

Incinerator Control Case

Chimney:10.0Meters

*(Update to Stainless Steel, free cost)

Italy oil/gas burner: 03 sets

Oil Tank (if Petroleum fuel): 500Liters

Design for Pets Cremation Business

Movable platform & Automobile.

Independent Position for Small Pet





















HICLOVER – Medical Environmental




WWW.HICLOVER.COM
Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



50 Kg Per Hour Incinerator

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Program Scope:  1. Hospital& practice: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine.  2. 3. Community & Sea Port & Station: Municipal Solid Waste, etc.  4. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Infectious Waste Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:nanjing clover
Origin:Nanjing Cn

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to sequence * High temperature, long lifetime of incinerator.  * Free or minimum installation on site.  *according to order  * New Design for pet animal cremation company.  * One year warranty on incinerator and components in stock.

Program Scope:  1. Hospital& practice: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine.  2. Slaughter House &Pet Hospital &Farm: Dead Animal, Bio-Waste.  3. Community & Sea Port & Station: Municipal Solid Waste, etc.  4. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation

Biomedical Waste Incinerator

Basic Info.

Model NO.:aravali incinerator of 30 kg per hour capacity co
Power Source:Diesel
Type:Incinerator
Usage:Incinerator
Export Markets:Global

Product Description

Items Specification
YD Model YD-30 / YD-50 / YD-100 / YD-150 / YD-200 / YD-300 / YD-500 / YD-600
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Mix Combustion Chamber
Smoke Filter Chamber
Incinerator Common Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Nanjing Clover Medical Technology Co., Ltd..

Incinerators

Basic Info.

Export Markets:Global

Product Description

Nanjing Clover Medical Technology Co., Ltd. is a leading waste incinerator manufacturer in China.

Items/Model A1500 A2400 A4000 A5500
Burning Rate *animal 90 kgs/Hr. 150 kgs/Hr. 200 kgs/Hr. 400 kgs/Hr.
Feed Capacity *animal 120 kgs 200 kgs 300 kgs 500 kgs
Equipment Weight 7000 kgs 8300 kgs 13000 kgs 16500 kgs
Primary Chamber (Liters) 1500 2400 4000 5500
Secondary Chamber (Liters) 500 1200 1500 1500
External Dimensions (cm) 240x170x380 260x220x420 320x220x460 360 x 220 x 475
Internal Dimensions (cm) 150x100x96 220x110x100 257x147x108 300 x 147 x 125
Oil Tank(Liters) 500 500 500 500
Door Opening (cm) 59 x 81 90 x 110 108 x 128 108 x 128
Chimney (M) 10 10 14 14
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long lifetime. *according to sequence * High temperature, long lifetime of incinerator.  * Free or minimal installation on site.  * PLC Control Plane. *according to order  * New Design for pet animal cremation company.  * One year warranty on incinerator and parts in stock.

Kazakhstan Medical Incinerators

Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Items Specification
YDC Model YD-10C / YD-20C / YD-30C / YD-50C
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Mix Combustion Chamber
Smoke Filter Chamber
Incinerator Common Control Case
Stainless Steel Chimney
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel)

Nanjing Clover Medical Technology Co., Ltd..

Small Scale Incinerators

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing

Product Description

Animal Waste Incinerator

Basic Info.

Model NO.:animal pet incinerator for sales
Export Markets:Global

Product Description

Items/Model A1500 A2400 A4000 A5500
Burning Rate *animal 90 kgs/Hr. 150 kgs/Hr. 200 kgs/Hr. 400 kgs/Hr.
Feed Capacity *animal 120 kgs 200 kgs 300 kgs 500 kgs
Equipment Weight 7000 kgs 8300 kgs 13000 kgs 16500 kgs
Primary Chamber (Liters) 1500 2400 4000 5500
Secondary Chamber (Liters) 500 1200 1500 1500
External Dimensions (cm) 240x170x380 260x220x420 320x220x460 360 x 220 x 475
Internal Dimensions (cm) 150x100x96 220x110x100 257x147x108 300 x 147 x 125
Oil Tank(Liters) 500 500 500 500
Door Opening (cm) 59 x 81 90 x 110 108 x 128 108 x 128
Chimney (M) 10 10 14 14
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Nanjing Clover Medical Technology Co., Ltd..

Incinerator Made by Clover

Basic Info.

Type:Medical Waste Incinerator
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Main Characteristics:  1, Using fever of gasifying combines burning technology. It applied to burn several kinds of medical waste, like syringes, infusion set, medical waste incinerator provider, medical equipment manufacturers, medication waste in china, mobile hazardous waste incinerators, mobile incinerator medical waste, disposable dressing, and also small animal, some town waste, like newspaper, tree leaves.  2, Closed vacuum-wide operation, applicable to deal with infectious medical waste and to prevent secondary pollution.  3, Complete design, easy to move to different location.  4, Combustion burner from China or Italy.

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Incinerator

Basic Info.

Model NO.:50 kgs per hour
Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Principle of the Incinerator equipment is incineration/combustion/burn.

Items/Model TS50(PLC)
Burn Rate 50 kg/hour
Feed Capacity 100kg
Control Mode PLC
Combustion Chamber 560L
Internal Dimensions 100x80x70cm
Secondary Chamber 280L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 12.1–24
Gas Consumption (m3/hour) 9.9–26.1
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 100L
Feed Door 70x55cm
Chimney 5Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800 degree –1000 degree
2nd. Chamber Temperature 1000 degree -1200 degree
Residency Time 2.0 Sec.
Gross Weight 4500kg
External Dimensions 230x130x155cm


Considering Environmental Protection requirements and principles, almost all incinerator have secondary combustion chamber (after-burn, post-combustion), even when third combustion chamber. The secondary burner burn the Exhaust gas from primary combustion chamber, this technology make sure adequate combustion, few black smoke and smell.  The updated incinerator technology focus on Exhaust gas treatment to eliminate Hazardous material and other purpose from incinerator, like heat recovery (waste to energy), save fuel cost, PLC Automation operation.  In some Developed countries, some new waste treatment method such as High-temperature cooking, waste carbonization, crushing sterilization technology is instead of incineration technology.

Pyrolytic Incinerator

Basic Info.

for Animal:All
Dosage Form:Incineration
Type:Cremation
Function:Cremation
Export Markets:Global

Additional Info.

Trademark:nanjing clover
Origin:Nanjing Clover

Product Description

Research and Markets: Waste: A Handbook for Management

The breadth of data included in this volume will make it the most comprehensive coverage of waste in the marketplace. It focuses on all of the main areas such as household waste (compostable material, newspaper, glass, textiles, household chemicals, plastic, water, e-waste), industrial and pet waste incinerator, pet. Crematory, pets cremation equipment, pets crematorium, pharmaceutical burning incinerator, pharmaceutical>waste label, pharmaceuticals waste, societal waste (metals, building, tires, medical battery, hazardous mining, nuclear, ocean, military, and space), and the future of landfills and incinerators. Including all the issues associated with waste in 1 volume will help lead to comparisons, synergistic solutions, and a more educated society. In addition to a detailed coverage of waste, this book will offer the best methods for managing the problems through recycling, incineration, landfill and other processes.

Twin Chamber Incinerator

Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Nanjing Clover Medical Technology Co., Ltd., Neighborhood in Nanjing city, China.

Two Chamber Medical Waste Incinerator

Basic Info.

Model NO.:tempreture of the stoker moving grate incinerator
Export Markets:Global

Product Description

Key Features:  * All models with Dual combustion chamber.  *according to order  * High fever, long life of incinerator.  * Free or minimal installation on site.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Key Features:  * All models with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High fever, long life of incinerator.  * Free or minimal installation on site.  * High burn rate, from 10kgs to 500kgs large medical incinerators, large scale clinical waste incinerator, bio medical incenarator manufacturer in china, bio medical waste incinerators manufacturers china, per hour, up to 6ton per day.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

Application Scope:  1. Hospital& clinic: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine.  2. Slaughter House &Pet Hospital &Farm: Dead Animal, Bio-Waste.  3. Community & Sea Port & Station: Municipal Solid Waste, etc.  4. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation

Items/Model YD-30 YD-50 YD-100 YD-150
Burning Rate (kgs/Hour) 30 kgs/Hr. 50 kgs/Hr. 100 kgs/Hr. 150 kgs/Hr.
Feed Capacity (kgs) 60 kgs 150 kgs 200 kgs 300 kgs
Equipment Weight 2300 kgs 4000 kgs 4300 kgs 7000 kgs
Primary Chamber (Liters) 360 900 1200 1500
Secondary Chamber (Liters) 200 200 500 500
External Dimensions (cm) 145x90x175 200x160x230 220x180x360 240x170x380
Internal Dimensions (cm) 100x60x60 120x90x85 130x100x90 150x100x96
Oil Tank(Liters) 200 300 300 500
Door Opening (cm) 48 x 60 62 x 80 55 x 80 59 x 81
Chimney (M) 5 5 10 10
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Efficient stove technology Alleviates N. Kenya’s medical waste problem

WAMBA, Kenya, June 30 (Thomson Reuters Foundation) – Poor weather, security threats and poor roads have made disposing of the Wamba district hospital’s medical waste a challenge.

The nearest incinerator is about 200 kilometres (125 miles) away and “travelling was not possible during heavy rains because linking roads were cut off by flooding,” stated Stephen Lesrumat, a medic in the hospital.

But now the north-central Kenyan hospital has a solution to its problems, and a means of cutting climate changing emissions and deforestation: A high-efficiency medical waste incinerator that uses just a fifth the fuel of a traditional incinerator.

The wood burner, which takes advantage of strong winds in the area to push the flames, borrows technology from fuel-efficient stoves. It can safely eliminate waste produced by the Wamba hospital and by 22 other health centers in Samburu County, stated Lesrumat and Ibrahim Lokomoi, the facility’s engineer.

“It has reduced the burden of traveling outside the county to eliminate medical waste,” Lesrumat said, sparing hospitals a potentially dangerous build-up of medical waste during periods when roads are impassible.

During previous flooding periods, when hospital waste could not be transported, “I was stressed because the waste is toxic,” Lesrumat stated. “It could lead to health and environment damage if it accidentally spilled into the community. ”

Run-ins with al Shabaab militants can also be a danger for some healthcare workers in Kenya driving long distances in their jobs, medics said.

“Northern Kenya is extremely expansive and has numerous challenges that the government struggles to provide services,” stated Onyango Okoth the assistant commissioner of Samburu County.

Currently the Wamba incinerator handles between 5 and 20 kilograms of medical waste a day.

As the burner works, a young employee clad in protective clothing flips open the lid of the chamber to monitor the process of incineration.

Seeing the last batch of waste is all but eliminated, he reaches for a cone containing a variety of used rubber gloves, syringes and polythene waste, pours in some of the waste, mixes it with a forked pole and then replaces the lid to allow the incineration to continue.

The Centers for Diseases Control in Kenya estimates that every patient admitted in a hospital generates at least 0.5 kilograms of medical waste.

The next step, Kenyan clean energy experts say, may be to start incinerating waste using more sustainable sources of energy, such as solar energy.

“Kenya is investing heavily in alternative energy sources,” said Johnson Kimani of the Kenya Climate Change Working Group. “Solar and biogas should be factored into medical waste incineration if the government is committed to its pledge of achieving a green market. ”

James Lebasha, of the International Medical Corps, which helped assemble the Wamba incinerator, said the burner might be just the first for the area.

“We hope to build more units in morthern Kenya to allow communities access this service,” he said. (Reporting by Kagondu Njagi; editing by Laurie Goering:Please credit the Thomson Reuters Foundation, the charitable arm of Thomson Reuters, that covers humanitarian news, climate change, women’s rights, trafficking and corruption.

“We hope to build more units in morthern Kenya to enable communities access this service,” he said. (Reporting by Kagondu Njagi; editing by Laurie Goering :; Please credit the Thomson Reuters Foundation, the charitable arm of Thomson Reuters, that covers humanitarian news, climate change, women’s rights, trafficking and corruption. Visit www.trust.org/climate)

from: http://www.reuters.com/article/2015/06/30/kenya-medical-energy-idUSL8N0ZG1M220150630

Pyrolytic Dual Chamber Incinerator Small Size:Burning Rate:30-45 kg/hr;Maximum Load Capacity:400 kg

Items/Model

TS50(PLC)


Principle

Solid Waste Incineration

Burn Rate

30-45 kg/hour

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

560L

Internal Dimensions

100x80x70cm

Secondary Chamber

280L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V

Oil Consumption (kg/hour)

Typical 13.3

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Display

Temperature Protection

Yes

Oil Tank

800L

Feed Door

70x55cm

Chimney

5Meter

Chimney Type

Stainless Steel

1st.

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

4500kg

External Dimensions

HICLOVER – Medical Environmental

230x130x155cm



Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



Medium Size:Burning Rate:60-80 kg/hr Pyrolytic Dual Chamber Incinerator

Items/Model

TS100(PLC)


Principle

Waste Incineration Treatment

Burn Rate

60-80 kg/hour

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

1200L

Internal Dimensions

120x100x100cm

Secondary Chamber

600L

Smoke Filter Chamber

Yes(Dry Scrubber)

Feed Mode

Manual

Voltage

220V

Oil Consumption (kg/hour)

Typical 20.4

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Screen

Temperature Protection

Yes

Oil Tank

1100L

Feed Door

80x60cm

Chimney

10Meter

Chimney Type

Stainless Steel

1st.

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

6000kg

External Dimensions

260x150x180cm


The requirement is for a pyrolytic double-chamber incinerator. The incinerator shall be capable of using diesel
fuel as a supplemental fuel oil.
It should incorporate an Air Pollution Control (APC) System suitable for basic emission control.
The proposed incinerators shall be appropriate for critical harsh environmental conditions, suitable for rapid
deployment, and different climate zones (e.g. desert, tropical country, mountain, etc.) in which there are several
variations of the relative natural forces (e.g. temperature, humidity, wind, etc.) for a minimum period of 10 years
if the specified maintenance schedule is followed.
The incinerators should be supplied assembled, whenever possible, and all parts and components should be
packaged on pallets in order to be transported via road, air (via helicopters or air-cargoes, e.g. MI8 or C130)
and via sea in a 20’ ISO sea shipping containers.

HICLOVER – Medical Environmental



Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



Large Size Burning Rate:150-200 kg/hr Solid Waste Equipment Primary and Secondary Combustion Chamber Incinerator

Items/Model

TS500(PLC)


Principle

Waste Incineration Treatment

Burn Rate

150-200 kg/hour

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

2700L

Internal Dimensions

190x120x120cm

Secondary Chamber

1300L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V

Oil Consumption (kg/hour)

Average 28

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Screen

Temperature Protection

Yes

Oil Tank

1400L

Feed Door

90x80cm

Chimney

10Meter

Chimney Type

Stainless Steel

1st.

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

15000kg

External Dimensions

The air supply should be controlled efficiently;
Flame contact with all the gases should be achieved;
The minimum combustion temperature of the primary chamber should not be less than 850°C;
The primary combustion chamber should be equipped with a means to provide supplemental liquid fuel supply.
The primary chamber should be cold face refractory lining, with a minimum thickness 100 mm.
The following conditions should be met in the secondary combustion chamber:
The air supply should be controlled efficiently;
Flame contact with all the gases should be achieved;
The size of the secondary chamber should be properly designed to ensure that the gas retention time should not be less than 2 seconds;
The secondary chamber should be cold face refractory lining, with a minimum thickness 100 mm;
The chamber should incorporate an integrated combustion burner air fans with automatically controlled distribution;
The gas temperature, as measured against the inside wall in the secondary chamber (not in the flame zone) should not be less than 1,100°C;

400x210x300cm(without chimney)

HICLOVER – Medical Environmental



Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



hiclover incinerator 100-150kgs per hour

Model

YD-100


Burning Rate

100-150 kgs/hour

Main Combustion Chamber

2000 Liters

Secondary Combustion Chamber

500 Liters

Feed Mode

Manual

Voltage

220V/380V

Power

2.5Kw

Fuel Type

Diesel Oil

Burner

Italy Original

Oil Consumption (Diesel Oil)

Typical 28 kg/hour

Gas Consumption (Natural Gas)

***

Internal Dimensions

180x115x98 cm (primary chamber)

External Dimensions

270x185x280cm (without chimney)

Temperature Monitor

Yes

Oil Tank Capacity(if Petroleum fuel)

200 Liters

Door Opening

55 x 80cm

Chimney Length

6.0 Meters

Chimney Type

Steel

Equipment Gross Weight

9000 kgs

Operation Technical Specifications

Main Chamber Temperature

800℃–-1000℃

Secondary Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Burning Efficiency

>98 percent

Waste Lower Calorific Power


HICLOVER – Medical Environmental

3500Kcal



WWW.HICLOVER.COM
Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



Large General waste incinerator Burn Rate up to 250kg per hour

Items/Model

TS300(PLC)

Principle

Waste Incineration Treatment

Burn Rate

Average 250 kg/hour

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

2000L

Internal Dimensions

170x120x100cm

Secondary Chamber

1000L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V

Power

2.5Kw

Oil Consumption (kg/hour)

Typical 28(DO)

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Screen

Temperature Protection

Yes

Oil Tank

1000L

Feed Door

80x60cm

Chimney

10Meter

Chimney Type

Stainless Steel

1st.

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

11000kg

External Dimensions

HICLOVER – Medical Environmental

400x210x300cm(without chimney)



WWW.HICLOVER.COM
Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.incinerator-scrubber.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
